Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane

  • Description
Is there a problem?<br>Please contact us to serve you!

Is there a problem?
Please contact us to serve you!

Inquiry
Wholesale Price Matrix Membrane Smart Switch With Ied Waterproof  Panel Membrane Switch Keyboard
Products Description
Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane factory

Membrane Switch With aluminumback support
six layers:
graphic overlay
Total thickness rang from 0.6-0.8mm
Overlay Material
PET, PC, EBG180, EGA180, Glass, Acrylic

Artwork Format
CorelDraw, AI, CAD, CDR, PDF

Color
Pantone and RALcolor matching system

Button options
Tactile: metal dome, poly dome, silicone button


Non-tactile: flat button, printed silver spot on the circuit
Connector
ZIF connector: 0.5mm, 1.0mm, 1.25mm pitch


Female connector with 2.54mmpitch
Circuit option
Silver printed conductive inks, FPC, PCB

Printing
Screen printing, Semi-Auto matic printing, Automatic Printing

Window
Transparent, translucent red/black/white etc window

Surface
Glossy surface or matte surface

Rear Adhesive
3M467,3M468, 3M9448MP, 3M300LSE, 3M93420 etc.

Certificate
ISO9001、RoHS、CE、TUV

Circuit level
35V (DC), 100mA, 1W
Contact resistance
10 Ω~ 500 Ω (varies according to the length and material of outgoing
Insulation impedance
100M Ω 100V
Dielectric withstand voltage
no breakdown or flashover after 250V RMS (50-60Hz 1min) test
Contact jitter time
≤5ms
Service life
plane type ≥5 million times
Touch type
≥1 million times
Operating pressure
plane type 57~ 284g (2 ~ 10oz)
Tactile type
170-397g (6-14oz)
Switch stroke
plane type 0.1~ 0.5mm
Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane factory

1、Cheap and cost-effective
2、Adjustable touch of buttons
3、Easy to clean and lightweight
4、The button can be used for glue dripping process

.
Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane details

1、High temperature resistance
2. Waterproof and UV resistant
3. Long service life, good pressure resistance and anti breakdown

Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane supplier

1、Adjustable touch of buttons
2、High lifespan
3、Laser with backlight effect
4、Imported raw materials and accessories


Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane factory
Recommend products
company strength
Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane supplier
About us
Dongguan Nanhuang Industry Co., Ltd. was founded in October 2000, headquartered Located in Zhangmutou Town, Dongguan City,Guangdong Province, with a plant area of 10,000 square meters. More than 20 years of focus, is engaged in丨membrane switch丨panel
The company has more than 20 utility model patents. The company has more than 20 utility model patents. The company has advanced production equipment, complete R & D laboratory, has passed the ISO9001 quality The company has passed ISO9001 quality system certification and strictly implements RoHS2.0 and EU environmental protection requirements.
Mini Membrane Switch Keypad Low-Priced Pushbutton Technology for Keyboard Switch membrane details
FAQ
Q1. What information will I have to provide for price?
A:To offer the exact price, we hope customers could inform us the material,specification as thickness, size, with adhesive or not, how many colors for printings, contact details, quantity required, Size and Shape with artwork files.

Q2. What is the production time?
(1)Custom sample: About 7 days.
(2)Mass production: About 2--3 weeks

Q3. Can you do the design for us?
Yes.
There ate many professional engineer having rich experience in graphic overlays& circuit designing.
Just let us know your ideas and we will help to carry out your ideas into perfect products.
If you send me your samples, we will design the drawings based on the samples and can revise the graphic of the face.


Q4. How about your delivery time?
A: After the engineering drawing is confirmed, the sample will be completed in 5 days, and after the sample is confirmed, the mass
goods will be completed in 10 days.The specific delivery time depends on the items and the quantity of your order.


Soushine


The Mini Membrane Switch Keypad is merely a pushbutton that is revolutionary is low-priced developed to boost your typing experience. Get ready to possess a seamless typing experience with this keyboard switch membrane layer this is certainly amazing.


The Soushine's Mini Membrane Switch Keypad is developed to final featuring its materials which can be top-quality. This keypad is built to withstand the rigors of day-to-day use. Having an exceptional typing experience that you simply won't find with other keyboards you you whether you are a gamer, a professional typist, or even a casual user, this keypad will give.


This membrane layer switch keypad is incredibly easy to use which consists of compact design and profile that is low that minimizes individual exhaustion. The buttons are soft to the touch and need pressure this is certainly minimal respond, rendering it ideal for users who do not want to stress their fingers while typing.


The membrane layer switch keypad is versatile, rendering it perfect for use with various kinds of products, including laptops, desktops, as well as other products that need high-quality tactile feedback. Soushine's Mini Membrane Switch Keypad is straightforward to include, it up therefore you won't need to stress about spending countless hours establishing.


Exactly why is the Soushine's Mini Membrane Switch Keypad be noticeable off their keyboards is its price that is tag that is ultra-low. Soushine has been able to craft this product this is certainly amazing sacrificing functionality or quality, making it extremely affordable for everybody. It really is simple to go through the things that are great superior typing aided by the Soushine Mini Membrane Switch Keypad, without breaking the financial institution.
